QUESTION PAPER, JANUARY, 2009

A1-R3: IT TOOLS AND APPLICATIONS

Note:

1. There are TWO PARTS in this Module/Paper. PART ONE contains FOUR questions and PART TWO contains FIVE questions.2. PART ONE is to be answered in the TEAR-OFF ANSWER SHEET only, attached to the question paper, as per the instructions contained therein. PART ONE is NOT to be answered in the answer book.3. Maximum time allotted for PART ONE is ONE HOUR. Answer book for PART TWO will be supplied at the table when the answer sheet for PART ONE is returned. However, candidates, who complete PART ONE earlier than one hour, can collect the answer book for PART TWO immediately after handing over the answer sheet for PART ONE.

TOTAL TIME : 3 HOURSTOTAL MARKS : 100PART ONE – 40; PART TWO – 60)PART ONE (Answer all the questions)

1. 1. Each question below gives a multiple choice of answers. Choose the most appropriate one and enter in the “tear-off” answer sheet attached to the question paper, following instructions therein.

1.1 Which one of the following is not an output device?

1. Plotter
2. Speech synthesizer
3. MICR
4. Smart and intelligent terminal

1.2 An example of a volatile memory is:

1. CD-ROM
2. RAM
3. ROM
4. HardDisk

1.3 What do folders enable a user to do?

1. Organize the files on a disk
2. Ensure the computer starts properly
3. Name your files
4. Create a file allocation table

1.4 Which of the following belongs to systems software?

1. Word processing software
2. Web browsers
3. Operating system
4. Spreadsheet software

1.5 A Time sharing system is:

1. Batch processing approach
2. Interactive multi-user multiprogramming approach
3. Single user system
4. Single user Multiprocessing approach

1.6 How does the keyboard’s Backspace key work?It erases characters to the left of the cursor.It erases characters to the right of the cursor.It moves the cursor left.It erases the character above the cursor.

1.7 Which keystroke will take you at the beginning of the next or previous page of the document?Ctrl + Page Up and Ctrl + Page DownShift + Home and Shift-EngCtrl + Home and Ctrol + EndThe only way is by sing the right scroll bar1.8 Which of the following menu option is used to display the Custom Animation task pane is Power Point by choosing Custom Animation optionFormatToolsSlide ShowWindow1.9 The advantage of using a spreadsheet is:Calculations can be done automaticallyChanging data automatically updates calculationsMore flexibilityAll of the above1.10 Which of the following allows you to communuicate with multiple users at the same time?E-mailA chat roomChat roomA photo community

2. 2. Each statement below is either TRUE and FALSE. Choose the most appropriate one and ENTER in the “tear-off” sheet attached to the question paper, following instructions therein.

2.1 A 16-bit CPU can process 2 bytes at a time.2.2 An electronic multiplexer can be considered as a multiple-input, single-output switch, and a de-multiplexer as a single-input, multiple-output switch.2.3 An EPROM is a type of computer memory chip and is non-volatile.2.4 Hard disk can be divided into one or more logical disks called partitions. This division is described in the partition table found in sector of the disk.2.5 Audio-output devices can output only music.2.6 Mnemonics are associated with machine language.2.7 MEM and CLS are internal DOS commands.2.8 You can add dates to worksheets. But spreadsheet cannot use dates in calculations.2.9 Linux is a proprietary software.2.10 The kernel is a program that constitutes the central core of a computer operating system.Q.3. Match words and phrases in column X with the closet related meaning/word(s)/ phrase(s) in column Y. Enter your selection in the “tear-off” answer sheet attached to the question paper, following instructions therein.

3.1 SCANDISK-	A. Utility to create disk partition
3.2 Auto Correct	B. Half a byte
3.3 Motherboard	C. parallel port
3.4 RS-232	D. relative cell reference
3.5 Resolution	E. utility that checks your hard disk for logical and physical errors on the drive.
3.6 Nibble	F. Inserts new text
3.7 Drivers	G. Series of program instructions that standardizes the format of data between a computer and peripheral device.
3.8 $A$1	H. The main circuit board of a microcomputer.
3.9. Memory	I. Serial port
3.10 latency	J. refers to the time delay
	K. DOS command
	L. refers to the amount of storage you have in your computer
	M. absolute cell reference
	N. translates assembly language programs into machine language
	O. The number of distinct pixels in each dimension that can be displayed.
	P. A collection, of format setting that you can apply to a paragraph or to selected text.

4. 4. Each statement below has a blank space to fit one of the word(s) or phrase(s) in the list below. Enter your choice in the “tear-off” answer sheet attached to the question paper, following instructions therein.

A. impact	B. workspace	C. Sequential	D. AutoFill
E. non-impact	F. Alt+Shift+X	G. Shell	H. DIP
I. Spreadsheet	J. CPU	K. MIPS	L. line spacing
M. spacing	N. Memory Management	O. Fill	P. Kernel

4.1 Multiprogramming systems are designed to maximize ___ usage4.2 Line printers and dot-matrix printers are _____ printers.4.3 Recording of data on tape is in ______ form.4.4 ________is a measure of a computer’s processing speed.4.5 The _____ is where the data will be entered and displayed.4.6 In Excel _______ allows the user to enter repetitive data quickly.4.7 The part of operating system that allows the user to communicate, or interact,4.8 Use _______ to mark terms you want to include in your index.4.9 ________ determines the amount of vertical space between lines of text in a paragraph.4.10 One of the main functions of the operating system is ­­­­_____PART TWO

5. 5. (A) What is the function of ALU in a microcomputer system?

(b) What is BIOS?(c) What is Pointing device? Name different types of pointing device?(d) Express the following binary fractions to their decimal equivalents:(0.111)(11011.101)

1. 6 (a) As working with Linux OS all files and directories have security permissions; what are those and how chmod command helps in operating all those permissiions?

(b) What are the three types of user interface?(c) What is the difference between systems software and applications software?Q.7. (a) What is a clipart? How clip art is inserted in MS-Word document?(b) What is the Normal Template?(c) What are Labels? Illustrae the methodology to enter Numbers as Labels in Excel sheet?(d) How is a macros defined and executed in Excel?Q.9. (a) Describe Slide Transition and Animation Features(b) What is the difference between embedded chart Sheet? What are Legends and how are they added on a chart?
